4x7 Rosin Plates DIY Uncaged Kit - Build A 12-30 Ton Rosin Press - Bottom Plate Holder Included
Features:
- Alignment & Safety - Upgraded version 4x7" uncaged kit allows the bottom platen to secure on the hydraulics for alignment and safety in the process of working.
- Innovative 8mm Slim Insulator - SGS certified food grade Insulation, heats up to 200F about 4-5 minutes and protects the hydraulics from overheating.
- 4x7" Heat Press Platens - Well suited to squeeze large amount at a time for industrial use; Pairs it well with a 20-ton hydraulic shop press
- Food-grade Working Surface - Dual heated platens made of anodized 6061 aluminum guaranteed to clean up easily.
- 4pc Heating Rods - Quick and even heating up with 1,200w PID temp controller box.
- Long Working Life Guaranteed - The heating rods have a service life of more than 6,000 times.
Specifications:
- Temperature Range: 0-399F
- Voltage: 110/220V
- Power: 1,200W
- Each Heater: 300W
- Plate Size: 4" x 7"
- Gross Weight: 13.86Lbs
Instructions to Secure Bottom Platen to Hydraulic Press Frame:
- Install the top heated plates onto the ram of the hydraulic press.
- Install the bottom heated plate using the long threaded rod through the bamboo insulation, then attached to the worktable plate.
- Lower the ram on the hydraulic press just until both plates touch.
- Adjust the position of the plates if necessary, so they are aligned.
- Ensure bamboo plank is aligned under the bottom plate.
- Tighten the nut on the long threaded rod to secure it to the worktable plate below.
How to Avoid the Filter Bags from Blowing out?
- Remove excess stems from flowers.
- Use less material in your filter bag.
- Preheating your material first to get it melty before you begin to apply pressure.
- Apply the pressure more slowly.
- How to choose filters and prepress molds.
- The yields are not very good, why?
- How to install the DIY press plates kits
- How to choose hydraulic press for pairing
- How to apply the pressure for optimal yield and quality?
- How to begin extracting.
- Important notice.
- Troubleshooting.
- Question and answer.
- Check it out here (Highly recommended to read it before doing a purchase).
PID TEMP CONTROLLER SETTING:
Press "SET" button to activate temperature controller
Press ◄ button to increase and decrease the value at hundreds, tens and one's places
Press ▼ or ▲ from 0-9 for your desired temp
Press "SET" button to lock the desired temperature in place
CHECK-UP BEFORE BUYING:
Love the plates. Staff is top notch and responded to every concern i had and helped me with a walkthrough on some internals. Turned PID on and plates instantly started heating up,leveled out and stayed at the temp i set. Love it, thanks Dabpress
Had a 20 ton shop press. Bought this item and was making rosin as soon as I got it. All the accessories work great with my press without mods. I really appreciated the bamboo insulator and silicone sheet.
Works fantastic, always a great result. Dab away my friend
Recommend it
I have only had my plates for a week and they seem to be very nice. But I do Have a 5° fluctuation on one of the plates it keeps going bouncing between the 5° but seems to be working very good I think a piece of insulation underneath that plate will fix everything
