3x3 DIY Uncaged Press Plates Kit - DIY 6 Ton Rosin Press Pairing It Well with 6-ton A-frame Press
- 3x3" Size Heated Plates - Pairs well with a 3-6 ton A-frame hydraulic shop press to build your own press; 3x3 " platen well suited to squeeze 3.5-7g material.
- Anodized Heated Platen - Anodized working surface is easy to clean up, and offers even heating.
- Accurate Temp Detected - Durable dual heating PID temp controller; Accurate temp delivered utilizing separate thermocouple and heating rods.
- Long Working Life Guaranteed - The heating rods have a service life of more than 6,000 times.
- Bottom Plate Holder Not Included - Please secure dual heated platens working in alignment; not including bottom plate holder for 3x3 kit.
Specifications:
- Temperature Range: 0-399F
- Voltage: 110/220V
- Power: 300W
- Plate Size: 3" x 3"
- Top Platen in Height: 2 3/8"
- Bottom Platen in Height: 1 1/8"
- External Package: 14" x 14.2" x 6.1"
- Gross Weight: 8.15lbs
How to Avoid the Filter Bags from Blowing out?
- Remove excess stems from flowers.
- Use less material in your filter bag.
- Preheating your material first to get it melty before you begin to apply pressure.
- Apply the pressure more slowly.
- How to choose filters and prepress molds.
- The yields are not very good, why?
- How to install the DIY press plates kits
- How to choose hydraulic press for pairing
- How to apply the pressure for optimal yield and quality?
- How to begin extracting.
- Important notice.
- Troubleshooting.
- Question and answer.
- Check it out here (Highly recommended to read it before doing a purchase).
User Manual & Troubleshooting Includes:
QUESTIONS & ANSWERS
Ask a Question-
I bent one of the tightening bolts on the plate so now when i tighten it the plates don't stay square, can i replace the bolt? If so do you know the size?
Please buy M8 screws, and replace the bent one. Have a nice day!
-
How much budd can I press at one time with these plates.
We recommend 1.5-7g small batches at a time, it is great to be paired a cylinder pre press mold for high yield ( bottle tech style pre press mold ).
